5 in 1 Cavitation Tripolar Multipolar Bipolar Rf Machine

Overview

This multifunctional aesthetic system integrates five technologies in a single platform, combining ultrasonic cavitation and multiple radiofrequency (RF) modalities. It is designed for professional use in treatments focused on body contouring, skin tightening, and facial applications.

The system incorporates multi-polar RF technology, enabling controlled energy delivery across different skin depths through specialized handpieces.

Integrated Technologies

1. 40KHz Ultrasonic Cavitation

Utilizes low-frequency ultrasound at 40 kHz to generate cavitation effects within targeted areas.

2. 5 MHz Tripolar Radiofrequency

Designed for body applications, delivering RF energy through three electrodes.

3. 5 MHz Bipolar Radiofrequency

Configured for facial and periocular areas, with controlled and localized energy distribution.

4. 5 MHz Multipolar Radiofrequency

Combines multiple electrodes in a single applicator to deliver RF energy across broader treatment zones.

5. Laser Integration (Multipolar Head)

The multipolar RF handle includes laser functionality, integrated within the same applicator for combined operation.

Technology Description

Multi-Polar Radiofrequency System

The system is developed using multi-polar RF technology, which combines monopolar and bipolar energy delivery methods within a single handpiece.

• Monopolar RF: Delivers energy at deeper tissue levels (up to approximately 20 mm).
• Bipolar RF: Targets more superficial layers (approximately 2–4 mm depth).
• Multipolar RF: Integrates multiple electrodes and control algorithms to manage energy distribution and adapt output parameters.

This configuration allows the system to operate across different tissue depths depending on the selected applicator and treatment protocol.

Key Features

• Multi-technology platform with 5 integrated functions
• 40KHz ultrasonic cavitation system
• Multiple RF modes: bipolar, tripolar, and multipolar
• Integrated laser within multipolar applicator
• Color touch screen interface for parameter control
• Energy delivery designed for different skin depths
• Configurable settings depending on treatment area

Technical Specifications

• Radiofrequency Frequency: 5 MHz
• Cavitation Frequency: 40 KHz
• Cavitation Power: Up to 6 W/cm²
• Total Power Consumption: 75 AV
• Voltage: AC 110V / 220V
• Frequency: 50 Hz / 60 Hz

Application Areas

This equipment is used in aesthetic practices for procedures involving:

• Body contouring protocols
• Skin tightening procedures
• Facial treatments
• Applications involving localized areas of the body
• Treatments using combined cavitation and RF technologies

How the Cavitation Technology Works

Ultrasonic cavitation operates by generating alternating compression and expansion cycles within a liquid medium. These cycles create microbubbles that expand and contract due to pressure variations.

This physical phenomenon, known as cavitation, produces mechanical effects within the targeted area. The process involves the formation of microscopic cavities (gas or vapor-filled spaces) that respond dynamically to ultrasonic waves.

What the Equipment Includes

• Main control unit with touch screen
• Cavitation handpiece (40KHz)
• Bipolar RF handpiece
• Tripolar RF handpiece
• Multipolar RF + laser handpiece
• Power supply and connection cables
